KRUEGER KLPS - Page 47

47
Fan Powered Terminal Units IOM
Brown to
Capacitor
Black #12
1 2 3 4 5 6
White #12 to
Terminal Block/
Diconnect Switch
Black #12 to
SCR Controller
Crimtie Wire 1
and Wire 4
Green
MOTOR
Brown to
Capacitor
Black #12
1 2 3 4 5 6
White #12 to
Terminal Block/
Diconnect Switch
Black #12 to
SCR Controller
Green
MOTOR
Brown to
Capacitor
Black #12
White #12 to
Terminal Block/
Diconnect Switch
Black #12 to
SCR Controller
Green
1 2 3 4 5 6
MOTOR
FIGURE 14 – PSC Motor Wiring Terminal
Block – 115V, Single Phase
FIGURE 15 – PSC Motor Wiring Terminal
Block – 208/240V, Single Phase
FIGURE 17 – PSC Motor Wiring Terminal
Block – 277V, Single Phase
