Table 6.B – RVE Basic Pressure and Airflow Data
RVE Basic Pressure and Airflow Data
Inlet Size (area ft² )
Maximum Airflow
(CFM)
Minimum Airflow
(CFM)
Flow Rate
(CFM)
Min ∆Ps ("WG)
4
(0.09)
230
40
40
0.007
103
0.048
167
0.126
230
0.239
5
(0.14)
360
62
62
0.008
161
0.052
261
0.137
360
0.261
6
(0.20)
515
90
90
0.007
233
0.05
377
0.131
520
0.249
7
(0.27)
700
121
120
0.007
330
0.056
525
0.142
700
0.252
8
(0.35)
920
160
160
0.008
440
0.059
675
0.138
920
0.256
9
(0.44)
1160
201
200
0.008
550
0.058
875
0.146
1160
0.257
10
(0.55)
1430
248
250
0.008
675
0.056
1075
0.142
1430
0.252
12
(0.78)
2060
357
360
0.008
1000
0.06
1550
0.143
2060
0.253
14
(1.07)
2800
486
480
0.008
1375
0.063
2125
0.149
2800
0.259
16
(1.40)
3660
634
630
0.008
1775
0.06
2725
0.141
3660
0.255
NOTES:
1.) ∆ Ps is the difference in static pressure across the assembly, with the damper fully
open.
2.) Minimum CFM value is based on a signal of 0.03 in w.g. differential pressure of the
inlet
