SEATPOST INSTALLATION
MINIMUM INSERTION DISTANCE
All seat post models must be inserted into the bicycle’s seat tube
to cover the minimum insertion line indicated on the seat post.
Insufficient insertion of the
seat post into the bicycle
frame’s seat tube could
result in damage to the
seat post and/or bicycle
and may result in a loss of
control of the bicycle which
may lead to serious injury or
death.
SEAT COLLAR TORQUE
Tighten your frame’s seat collar to a maximum torque of 5 N-m.
Do not over torque your frame’s seat collar as this may inhibit
proper function of your seat post.
5 N-m
Do not over torque your
frame’s seat collar as this
may inhibit proper function
of your seat post.
Seat Collar
5
