Torque Requirements – Bearing Assembly Clamp Bolts
ENGLISH FASTENERS – Grade 8
Size
A
nti-Sieze Lubricated / Oiled
ft-lbs N-m ft-lbs N-m
3/4 “ 225 305 280 380
1” 550 750 680 920
1 1/8” 800 1085 960 1300
1 1/4” 1150 1560 1360 1840
1 1/2” 1900 2575 2660 3600
1 3/4” 3000 4060 4600 6200
2” 4500 6100 6500 8800
Torque Requirements – Bearing Assembly Clamp Bolts
METRIC FASTENERS – Class 10.9
Size
A
nti-Sieze Lubricated / Oiled
ft-lbs N-m ft-lbs N-m
M20 275 375 300 400
M24 450 610 500 700
M27 650 880 800 1075
M30 915 1250 1175 1600
M36 1630 2200 2250 3025
M42 2590 3500 3700 5025
M48 3800 5150 5575 7550
M52 4740 6425 7040 9450
