▓ECU PIN ASSIGN
ECU pin assignment display page: (EMS,PSD,P1M1)
1 11
12 17 22
1:DRVG [G ] Controller GND
2:LSD1 [] Reserved
3:FIND [G/B ] Injector O/P
4:LSD2 [Y/G ] MIL O/P
5:FPDD[B/Blue] Fuel Pump relay O/P
6:IMMS [] Reserved
7:TPIM[L/R ] TPS I/P
8:MAPM [L/B ] BARO sensor I/P
<Enter>return<LEFT>prev.page<RIGHT>next page
(KEIHIN)
1 10 18
19 36
1: IGP [R/Y] B+
2:
3: CRK-P [G/W] Crankshaft pos. sensor+
4:
5: TH [W/Br] Throttle angle(A/D)
6: PM [B/R] Manifold press. SNSR I/P(A/D)
7: HEGO [Pink/B] O2 sensor(A/D)
8: LG [G] shield GND
<Enter>return<LEFT>prev.page<RIGHT>next page
