44
6.2.2 DATA STREAM
SYM
1.ECU ID
2.DATA STREAM
3.TROUBLE CODE
4.RECORDED TB CODE
5.HISTORY TB CODE
6.ERASE TB CODE
7.CO ADAPTION
8.SET-RESET
▓DATA STREAM Page:（EMS）
（01-04） DATA STREAM
（03-04） DATA STREAM
Engine SPD--1614RPM(Idle
1550~1750)
Intake Air---------53'C(40~60'C)
Intake Air-----2.10V
Engine temp-------102'C(90~120'C)
Engine temp---1.34V
BARO----------102.5Kpa
BARO-----4.17V
TPS----------0%
TPS----------0.70V
CO METER-----4.17V(Idle 0.5~2.5V)
Engine SPD--1614RPM(Idle
1550~1750)
Engine temp------102'C(90~120'C)
BARO---------102.5Kpa
RUN TIME----222Hr
BYPASS OPEN------202'(100~250')
FUEL PUMP----ON
Intake Air--------68'C
TOTAL APC---------44
ABV TIME-----0mS
ABV RESET---0mS
