KSR IDS-101 - Page 74

70
▓Fixed display:
▓The left side appear
“@”,namely fixed item.
▓Data item waveform
▓After individual item is
fixed, press [F2] key,
show the instant
waveform.
▓Pressing [up] key can
enlarge the waveform,
press the [down] key and
narrow the waveform.
（01-03） DATA STREAM
@IAP COMP.--------------------kpa
IAP CMD------------------------kpa
IAP ANGLE----------------------CA
O2S SENSOR VALID---------------
O2S SENSOR VALID #2------------
O2S VOLT.---- -----------------mV
O2S VOLT#2---------------------mV
ENGINE RPM--------------------rpm
TPS---------------------------pct
TPS COMP.-------------------------------pct
（01-03） DATA STREAM
Engine speed----------RPM
20000
0
