KTC COMPACK 2 - TECHNICAL DATA COMPRESSOR

CONFIDENTIAL - This document is the property of K.T.C. S.r.l. and cannot be reproduced or issued to third parties without written authorization. K.T.C. shall safeguard its rights to the full extent of the law.
USER MANUAL AND INSTALLATION
COD. 091052 - REV. 07 - DATE 11/2016
Pag.14 di 45
2 TECHNICAL DATA COMPRESSOR
• When the environmental temperature is below 5 ° C is necessary to choose a lubricant ISO VG 32.
• For temperatures below 0° adopt a heater for the specific oil. If necessary, contact an authorized service center KTC.
** Value detected at the maximum operating pressure
*** Sound level measured in free field at 1 meter ± 3 dB (A) at maximum operating pressure.
Model
COMPACK 2 V230/3/50
10 bar
COMPACK 2 V400/3/50
10 bar
Machine type
Oil injected screw compressor
Oil injected screw compressor
Drive
Direct coupling
Direct coupling
Type of screw
ADAM S60 C
ADAM S60 C
Flow rate (ISO 1217 annex B 1996)
0.29 m
3
/min - 10.24 cfm
0.29 m
3
/min - 10.24 cfm
Max. working pressure
10 bar g - 145 psi g
10 bar g - 145 psi g
Min. working pressure
5 bar g - 72.5 psi g
5 bar g - 72.5 psi g
Maximum power consumption**
3.0 kW - 4 hp
3.0 kW - 4 hp
Max. air/oil outlet temperature
105 °C - 221°F
105 °C - 221°F
Max. environmental temperature
45 °C - 113 °F
45 °C - 113 °F
Min. environmental temperature*
5 °C - 41 °F
5 °C - 41 °F
Weight
40 kg - 88.2 lb
40 kg - 88.2 lb
Power Supply Voltage
230/3/50
400/3/50
Max. current consumption
11,5 A
6 A
Degree of electrical motor protection
IP 54
IP 54
Class of insulation
F
F
Service Factor
S1
S1
Oil Quantity
1.5 lt
1.5 lt
Air Outlet connection
3/8”
3/8”
Oil residue in air
< 3 ppm
< 3 ppm
Electrical Motor
MEC90
MEC90
Heating Oil Resistance
24 V / 35 W / 1,5 A
24 V / 35 W / 1,5 A
Sound Level***
< 70 dBA
< 70 dBA
Air Tank Capacity
/
/
