13 SERVICE WORK ON THE CHASSIS 116
M00896-11
–
Mount and tighten screw
.
Guideline
Screw, mask spoiler M5x17 3.5 Nm
(2.58 lbf ft)
– Repeat the operation on the opposite side.
Finishing work
– Install the tank cover. ( p. 119)
– Install the front side cover. ( p. 110)
– Mount the seat. ( p. 97)
13.22 Removing the front fender
K00024-11
–
Open the holder
and detach the brake lines.
–
Remove screws
.
– Remove the fender in a forward direction.
Info
Pay attention to the brake lines.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 1050 Adventure and is the answer not in the manual?

KTM 1050 Adventure Specifications

General IconGeneral
Displacement1050 cc
Transmission6-speed
Fuel Tank Capacity23 liters
Seat Height850 mm
Bore x Stroke103 mm x 63 mm
Fuel SystemElectronic Fuel Injection
Cooling SystemLiquid cooled
ABSBosch 9M+ two-channel ABS
Compression Ratio12.5:1
StarterElectric
Engine Type2-cylinder, 4-stroke
Power95 hp
Torque107 Nm
Front SuspensionWP USD, 43 mm
Rear SuspensionWP monoshock
Front Brake4-piston calipers
Rear Brake267 mm disc, 2-piston caliper
FrameChromium-Molybdenum steel trellis
Front Wheel19 inch
Rear Wheel17 inch
Dry Weight212 kg (467 lbs)
