KTM 1290 SUPER ADVENTURE R 2021 User Manual

SERVICE WORK ON THE CHASSIS 13
103
E02379-10
–
Remove screws
3
.
–
Remove screw
4
with the bushing.
– Carefully take off the right side fairing from the side.
13.25 Installing the front side cover
E02379-11
Main work
– Position the right side fairing.
Guideline
The side fairing is located in area
A
under the mask
spoiler.
–
Mount and tighten screws
1
.
Guideline
Screw, cover part M5 3.5 Nm
(2.58 lbf ft)
–
Mount and tighten screw
2
.
Guideline
Screw, seat bushing M6x16 4 Nm (3 lbf ft)

KTM 1290 SUPER ADVENTURE R 2021 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Transmission	6-speed
Fuel Tank Capacity	23 liters
Seat Height	880 mm
Dry Weight	221 kg
Rear Suspension	WP XPLOR PDS shock absorber
Front Tire	90/90-21
Rear Tire	150/70-18
Compression Ratio	13.1:1
Starter	Electric
Cooling System	Liquid cooled
Lubrication	Forced oil lubrication with 3 oil pumps
Traction Control	MTC (Motorcycle Traction Control), lean-angle sensitive
Power	160 hp
Torque	138 Nm
Front Suspension	WP XPLOR 48 mm, fully adjustable
Front Brake	Dual 320 mm discs, 4-piston calipers
Rear Brake	Brembo 2-piston caliper, 267 mm disc
ABS	Bosch 9.1MP (Cornering ABS)
Ground Clearance	250 mm
Fuel System	Keihin EFI
Frame	Chromium-Molybdenum steel trellis frame, powder coated
