7 COMBINATION INSTRUMENT
58
7.8 Coolant temperature indicator
F01466-11
The coolant temperature display is shown in segment
1
of the
display.
The coolant temperature indicator consists of bars. The more bars
that light up, the hotter the coolant.
Note
Engine failure Overheating damages the engine.
– If the coolant temperature warning is displayed, stop imme-
diately and take care not to endanger yourself or other traffic
participants in the process.
– Allow the engine and cooling system to cool down.
– Check and, if necessary, correct the coolant level on the cool-
ing system while it is in a cooled state.
Info
When all the bars light up, the warning High Coolant Tem-
perature appears on the display.
If the cooling system overheats, the maximum engine
speed is limited.
Possible states
• The engine is cold – Up to three bars light up.
• Engine warm – Four to ten bars light up.

KTM 200 Duke US 2020 Specifications

General

Displacement	199.5 cc
Bore x Stroke	72 mm x 49 mm
Compression Ratio	11.5:1
Fuel System	Electronic Fuel Injection
Transmission	6-speed
Starter	Electric
Frame	Steel trellis frame
ABS	Yes
Front Tire	110/70-17
Rear Tire	150/60-17
Engine Type	1-cylinder, 4-stroke engine
Power	19 kW (26 hp) at 10, 000 rpm
Torque	19 Nm @ 8, 000 rpm
Front Suspension	USD forks, 43 mm
Rear Suspension	Monoshock
Front Brake	300 mm disc
Rear Brake	230 mm disc
Ground Clearance	170 mm
Fuel Capacity	13.4 liters
