TECHNICAL DATA 23
157
Fuel connection on fuel pump M8 15 Nm (11.1 lbf ft)
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft)
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Nut, rim lock M8 12 Nm (8.9 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp
(EXC‑F Six Days)
M8 15 Nm (11.1 lbf ft)
Screw, bottom triple clamp (EXC‑F
EU/BR)
M8 15 Nm (11.1 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, engine brace on engine M8x20 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, engine brace on frame M8x15 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, manifold on cylinder head
brace
M8 15 Nm (11.1 lbf ft)
Screw, side stand attachment M8 33 Nm (24.3 lbf ft)
Loctite
®
2701™
Screw, subframe bottom M8 30 Nm (22.1 lbf ft)
Loctite
®
2701™
Screw, subframe top M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Screw, top steering stem
(EXC‑F Six Days)
M8 17 Nm (12.5 lbf ft)
Loctite
®
243™
Screw, top steering stem (EXC‑F
EU/BR)
M8 20 Nm (14.8 lbf ft)
Screw, top triple clamp
(EXC‑F Six Days)
M8 17 Nm (12.5 lbf ft)
Screw, top triple clamp (EXC‑F
EU/BR)
M8 20 Nm (14.8 lbf ft)
Engine attachment bolt M10 60 Nm (44.3 lbf ft)
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, handlebar holder M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Nut, fuel pump fixation M12 15 Nm (11.1 lbf ft)
Screw, bottom shock absorber M12 80 Nm (59 lbf ft)
Loctite
®
2701™
Screw, top shock absorber M12 80 Nm (59 lbf ft)
Loctite
®
2701™
Nut, fork pivot M16x1.5 100 Nm (73.8 lbf ft)
Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft)
Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft)
