TECHNICAL DATA 22
149
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, bottom shock absorber M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, top shock absorber M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Nut, angle lever to link fork M16x1.5 60 Nm (44.3 lbf ft)
Nut, fork pivot M16x1.5 100 Nm (73.8 lbf ft)
Nut, frame on linkage lever M16x1.5 60 Nm (44.3 lbf ft)
Nut, linkage lever on angle lever M16x1.5 60 Nm (44.3 lbf ft)
Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft)
Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft)
Nut, rear wheel spindle M22x1.5 80 Nm (59 lbf ft)
Screw-in fitting, cooling system M24x1.5 7.5 Nm (5.53 lbf ft)
