TECHNICAL DATA 22
241
Screw, passenger footrest unit M8 22 Nm (16.2 lbf ft)
Loctite
®
243™
Screw, rear brake disc M8 21 Nm (15.5 lbf ft)
Loctite
®
243™
Screw, rear seat fixing M8 18 Nm (13.3 lbf ft)
Screw, seat support plate M8 18 Nm (13.3 lbf ft)
Screw, subframe M8 25 Nm (18.4 lbf ft)
Loctite
®
620™
Screw, top triple clamp M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8x1 30 Nm (22.1 lbf ft)
Loctite
®
243™
Banjo bolt, brake line M10 24 Nm (17.7 lbf ft)
Fitting side stand M10 35 Nm (25.8 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, engine bearer M10 49 Nm (36.1 lbf ft)
Loctite
®
243™
Fitting, handlebar support M10x1.25 21 Nm (15.5 lbf ft)
Fitting, shock absorber, bottom M10x1.25 51 Nm (37.6 lbf ft)
Loctite
®
243™
Nut, left rear mirror M10x1.25 16 Nm (11.8 lbf ft)
Nut, right rear mirror M10LHx1.25 16 Nm (11.8 lbf ft)
