22 TECHNICAL DATA
242
Nut, side stand bracket M10x1.25 35 Nm (25.8 lbf ft)
Screw, combination instrument
bracket
M10x1.25 21 Nm (15.5 lbf ft)
Screw, front footrest bracket M10x1.25 44 Nm (32.5 lbf ft)
Loctite
®
243™
Screw, front footrest bracket /
engine bearer
M10x1.25 49 Nm (36.1 lbf ft)
Screw, top shock absorber M10x1.25 51 Nm (37.6 lbf ft)
Loctite
®
243™
Stud, rear sprocket M10x1.25 50 Nm (36.9 lbf ft)
Nut, rear wheel spindle M14x1.5 98 Nm (72.3 lbf ft)
Nut, swingarm pivot M14x1.5 98 Nm (72.3 lbf ft)
Screw, steering head, top M16x1.5 49 Nm (36.1 lbf ft)
Loctite
®
243™
Lambda sensor M18x1.5 19 Nm (14 lbf ft)
Adjusting ring, link fork bearing M22x1 Tighten and ensure that there is no
play
