ENGLISH
35
Changing oil filter *
Replace the oil filter when changing the engine oil. Press the foot brake lever and
place a screwdriver or similar between foot brake lever and stopper roll so that the
oil filter cover is more accessible. Remove banjo bolt
1 and the three allen head
screws. Remove oil filter cover
2 and oil filter. Clean filter case, oil filter cover,
and sealing surfaces. Check oil chanel in oil filter cover if clogged.
The O-ring
3 need not be replaced unless it is damaged. Press the O-ring into the
groove of the oil filter cover, mount a new oil filter
4 on the oil filter cap and
mount the unit. Insert the 3 screws and tighten them with 5 Nm (4 ft.lb). Mount
the banjo bolt with the gaskets and tighten it with 15 Nm (11 ft.lb).
Then start the engine and check the oil system for leaks.
1
2
1
2
3
4
