MAINTENANCE ON CHASSIS AND ENGINE 122
100070-10
–
Remove the rear brake linings. x ( p. 118)
– Remove screw with membrane .
– Press the brake piston back to its basic position and make sure that no brake fluid over-
flows from the brake fluid reservoir.
–
Install the rear brake linings. x ( p. 119)
– Add brake fluid to level .
Brake fluid DOT 4 / DOT 5.1 ( p. 190)
– Mount screw with membrane .
Info
Clean up overflowed or spilt brake fluid immediately with water.
9.51Removing wheel/wheels
Info
Proceed in the same way on the other wheels if necessary.
– Pull handbrake lever, push the locking pawl downwards, and release the handbrake
lever. (Figure 100006-10 p. 30)
