MAINTENA
NCE
ON
CHASSIS
AND
ENGINE
137
300251-10
–
Mount
and
tighten
screws
on
the
radi
ator.
Guideline
Remaining
screws,
chas
sis
M6
10
Nm
(7.4
lbf
ft)
–
Mount
and
tighten
screws
on
the
fuel
tan
k.
Guideline
Screw
on
fuel
tank
M6
6
Nm
(4.4
lbf
ft)
–
Mount
the
seat.
(
p.
134)
9.66
Removing
the
front
cover
300252-10
–
Remove
screw
.
–
Slide
the
front
cover
up
and
remove
it.
138
140
