TECHNICAL DATA - CHASSIS »
ENGLISH
8
TIGHTENING TORQUES – CHASSIS
Collar screw, front wheel spindle M24x1,5 40 Nm
Brake caliper, FTE radial front M10x1,25 40 Nm
Brake disks M6 Loctite 243 + 14 Nm
Clamping screws, upper fork bridge M8 17 Nm
Clamping screws, lower fork bridge M8 12 Nm
Clamping screws, fork stubs M8 15 Nm
Hexagon nut, swing arm bolt M16x1,5 100 Nm
Hexagon collar screw, handlebar clamp M8 20 Nm
Allan head srew, handlebar support M10 Loctite 243 + 40 Nm
Shock absorber, top M12 70 Nm
Shock absorber, bottom M12 70 Nm
Collar nut, swing arm bolt M20x1,5 80 Nm
Sprocket Screws M8 35 Nm
Ball joint for push rod M6 10 Nm
Engine mounting bolt M10 60 Nm
Engine brace M8 33 Nm
Spoke nipple M4,5 / M5 5 Nm
Screw adjusting ring spring preload shock abs. M6 8 Nm
Other screws on chassis
M6
M8
M10
10 Nm
25 Nm
45 Nm
Other collar nuts on chassis
M6
M8
M10
15 Nm
30 Nm
50 Nm
