TECHNICAL DATA - CHASSIS »
STANDARD ADJUSTMENT – FORK
450 / 560 SMR
WP 4860 PA/MA
14.18.7B.18
Compression adjuster 19
Rebound adjuster 17
Spring 4,6 N/mm
Spring preload 20 mm
Air chamber length 100 mm
Fork oil 4860 0401 Motorex
STANDARD ADJUSTMENT – SHOCK ABSORBER
450 / 560 SMR
WP 5018 PDS DCC
12.18.7B.15
Compression adjuster 13 LS (low speed)
2 HS (high speed)
Rebound adjuster 19
Spring 88/250
Spring preload 8 mm
CHASSIS 450 SMR 560 SMR
Frame Central tube chrome-moly-steel frame
Fork WP Up Side Down 4860 PA/MA
Wheel travel front/rear 285/310 mm
Rear suspension WP Progressive Damping System shock absorber aluminium swing arm
Front brake Disk brake with carbon-steel brake disc Ø 310 mm brake caliper radial
Rear brake Disk brake with carbon-steel brake disc Ø 220 mm brake caliper floated
Brake disc Wear limit max. 0,4 mm
Front tires 120/75 R 17 KR 106
Front rim 3,50x17“
Rear tire 165/55 R 17 KR 108
Rear rim 5,00x17“
Fuel tank capacity 7 liters
Final drive ratio 14:45Z
Chain 5/8 x 1/4"
Available final sprockets 38Z, 40Z, 42Z, 45Z, 48Z, 49Z, 50Z, 51Z, 52Z
Steering head angle 63,5°
Wheel base 1481 ± 10 mm
Seat height, unloaded 855 mm
Ground clearance, unloaded 310 mm
Weight 108,5 Kg 109,5 Kg
ENGLISH
7

KTM 450SMR Specifications

General

Engine Type	Single cylinder, 4-stroke
Bore/Stroke	95 mm / 63.4 mm
Compression Ratio	12.75:1
Starter	Electric starter
Transmission	5-speed
Cooling	Liquid cooled
Seat Height	890 mm
Final Drive	14:45
Ignition	Keihin EMS
Subframe	Aluminum
ABS	No
Displacement	449.9 cm³
Front Suspension	WP XACT-USD, Ø 48 mm
Rear Suspension	WP XACT Monoshock with linkage
Front Brake	Disc brake 310 mm
Rear Brake	Disc brake 220 mm
Fuel Tank Capacity	7.5 liters
Lubrication	Forced oil lubrication with 2 pumps
Clutch	Wet multi-disc clutch, hydraulically operated
Handlebar	Aluminum, tapered
Chain	520
Frame	Central tube frame made of chrome molybdenum steel tubing
