TECHNICAL DATA - CARBURETOR TIGHTENING TORQUES 149
7(&+1,&$/ '$7$  &$5%85(725 7,*+7(1,1* 72548(6
Leakage nozzle M4x0,7 2Nm (1.48lbfft) ಥ
Screw, throttle slide arm M4 2Nm (1.48lbfft) Loctite
®
243™
Screw, hose connection M4 2Nm (1.48lbfft) Loctite
®
243™
Other screws, carburetor M4 2Nm (1.48lbfft) ಥ
Idle air jet M4,5x0,75 2Nm (1.48lbfft) ಥ
Main jet M5x0,75 2Nm (1.48lbfft) ಥ
Cold start jet M5x0,75 2Nm (1.48lbfft) ಥ
Screw, throttle valve sensor M5 3.5Nm (2.58lbfft) ಥ
Idling jet M6x0,75 2Nm (1.48lbfft) ಥ
Needle jet M7x0,75 3.5Nm (2.58lbfft) ಥ
Needle screw/slide stop M8 3.5Nm (2.58lbfft) ಥ
Choke slide M12 2.5Nm (1.84lbfft) ಥ

KTM 530 EXC-R EU Specifications

General

Bore x Stroke	95 mm x 72 mm
Transmission	6-speed
Fuel System	Electronic fuel injection
Fuel Tank Capacity	8.5 liters
Starter	Electric starter
Frame	Central double-cradle type 25CrMo4 steel
Rear suspension	WP monoshock
Front brake	Disc brake
Rear brake	Disc brake
Front tire	90/90-21
Rear tire	140/80-18
Engine Type	Single cylinder, 4-stroke
Clutch	Wet multi-disc clutch
Front suspension	WP USD Ø 48 mm
