KTM 690 Duke 2017 - User Manual

Questions and Answers

K
Karen MyersAug 18, 2025
Why does my KTM 690 Duke 2017 Motorcycle engine turn over but not start?
- A
  Andrew DanielAug 18, 2025
  If your KTM Motorcycle engine turns over but doesn't start, consider these possibilities: It could be due to an operating error, so make sure you are using the correct start procedure. A blown fuse 3 could be the problem, so replace it. Check that the plug-in connection of the fuel hose is properly connected. Also, avoid opening the throttle while starting. A very dirty air filter (remove or install it) or fuel filter (check the fuel pressure) can also prevent the engine from starting.
C
Christine Green MDAug 21, 2025
Why is my KTM 690 Duke 2017 Motorcycle experiencing high oil consumption?
- D
  Diane PenningtonAug 21, 2025
  If your KTM Motorcycle has high oil consumption, it could be due to the engine oil level being too high, so check and adjust it. Another reason might be that the engine oil is too thin (low viscosity). If so, change the engine oil and oil filter and clean the oil screens.
Z
zacharyyoungAug 23, 2025
Why KTM Motorcycle engine won't crank when pressing the electric starter?
- S
  sgrimesAug 23, 2025
  If your KTM Motorcycle engine doesn't crank when you press the electric starter, it could be due to several reasons. It may be an operating error, so ensure you are following the correct start procedure. The battery might be discharged, requiring a recharge and open-circuit current check. A blown fuse (1, 2, or 3) or the main fuse could also be the issue, necessitating replacement. Finally, check the ground connection to ensure it's properly connected.
K
Kevin ReedAug 26, 2025
What to do if my KTM 690 Duke 2017 Motorcycle engine overheats?
- K
  Kristin PetersenAug 26, 2025
  If your KTM Motorcycle engine is overheating, several factors could be responsible. Check for coolant leaks and ensure the coolant level in the compensating tank is adequate. Dirty radiator fins can also cause overheating, so clean them. Other potential causes include foam formation in the cooling system (in this case you should drain and refill the coolant), a buckled or damaged radiator hose (replace it), a faulty thermostat (check it), a blown fuse 4 (replace it), or a defect in the radiator fan system (check it).
C
cherylcopelandAug 28, 2025
How to fix a discharged battery on my KTM 690 Duke 2017 Motorcycle?
- C
  Christy CunninghamAug 28, 2025
  If your KTM Motorcycle battery is discharged, it might be because the ignition wasn't switched off when parked. In this case, recharge the battery. Another reason could be that the battery is not being charged by the alternator. To solve this, check the charging voltage and the open-circuit current.
K
Kayla HudsonAug 30, 2025
What to do if my KTM Motorcycle engine dies while riding?
- M
  Michael PetersAug 30, 2025
  If your KTM Motorcycle engine dies during a trip, the first thing to check is whether you're out of fuel; if so, refuel. Another potential cause is a blown fuse (1, 2, or 3), which would require replacing the affected fuse.
E
Elizabeth JonesSep 1, 2025
Why is the ABS warning lamp on my KTM 690 Duke 2017 lit?
- D
  David AndersonSep 1, 2025
  If the ABS warning lamp lights up on your KTM Motorcycle, it could be due to a blown ABS fuse, so replace the ABS fuses. It might also indicate a large difference in wheel speeds between the front and rear wheels; in this case, stop the vehicle, switch off the ignition, and start it again.
J
jennifer65Sep 4, 2025
What does it mean when the FI warning lamp (MIL) lights/flashes on my KTM 690 Duke 2017?
- O
  owongSep 4, 2025
  If the FI (Fuel Injection) warning lamp lights or flashes on your KTM Motorcycle, it indicates a defect in the fuel injection system.
K
Kimberly AllenSep 6, 2025
Why are the headlight and parking light not working on my KTM 690 Duke 2017?
- S
  Stephanie EatonSep 6, 2025
  If the headlight and parking light aren't working on your KTM Motorcycle, the cause may be a blown fuse 6. Replace the fuse to resolve the issue.
E
Elizabeth SmithSep 8, 2025
Why are the turn signal, brake light, and horn not working on my KTM 690 Duke 2017 Motorcycle?
- R
  Rebecca GallagherSep 8, 2025
  If the turn signal, brake light, and horn are not working on your KTM Motorcycle, it is possible that fuse 5 is blown. Replace the fuse.

Summary

Safety Advice

Intended Use and Misuse

General Safety Instructions

Risk Levels and Symbols

Safe Operation Guidelines

Details safety precautions like rider fitness and exhaust gases.

Protective Clothing and Work Rules

Stresses protective gear and outlines rules for maintenance.

Controls and Switches

Handlebar Controls Overview

Left Handlebar Switches

Right Handlebar Switches

Brake Levers and Side Stand

Combination Instrument Functions

Indicator Lamps Explained

TC;ABS and Drive Mode Settings

Explains TC/ABS modes and Drive Mode selection.

Preparing for Use

Advice on First Use and Running In

Provides essential advice for first use, safety, and engine break-in.

Vehicle Loading Guidelines

Covers safe loading practices, weight limits, and baggage securing.

Riding Instructions

Pre-Ride Checks and Starting Procedure

Lists pre-ride checks and details the engine starting procedure.

Starting Off, Shifting, and Riding

Provides guidance on starting off, gear shifting, and riding techniques.

Braking, Stopping, and Parking

Covers brake application, stopping, parking, and transport.

Refueling Safely

Details safe refueling procedures and fuel type requirements.

Service Schedule

Tuning the Chassis

Fork and Shock Absorber Adjustments

Service Work on the Chassis

Chain Maintenance and Tension

Explains chain cleaning, tension checking, and adjustment.

Sprocket Wear and Clutch Fluid

Brake System

Antilock Braking System (ABS)

Explains the ABS system, its components, and associated warnings.

Brake Lever and Disc Adjustments

Brake Fluid and Lining Checks

Explains checking brake fluid levels and linings for front/rear brakes.

Foot Brake Lever Free Travel and Adjustment

Guides on checking and adjusting foot brake lever free travel.

Wheels and Tires

Front Wheel Removal and Installation

Rear Wheel Removal and Installation

Tire Condition and Pressure Checks

Guides on checking tire condition, tread, and pressure.

Electrical System

Battery Removal and Installation

Guides on safely removing and installing the motorcycle battery.

Battery Recharging and Fuse Changes

Provides instructions for battery recharging and fuse replacement.

Headlight and Lighting Component Maintenance

Cooling System

Coolant Level and Antifreeze Checks

Provides safety warnings and guidance for checking coolant level.

Coolant Draining and Filling

Provides instructions for draining and filling the cooling system.

Tuning the Engine

Shift Lever Position Adjustment

Drive Mode and Traction Control Settings

Explains selectable Drive Modes and Motorcycle Traction Control.

Service Work on the Engine

Engine Oil Level Check and Oil Change

Guides on checking engine oil level and performing oil change.

Adding Engine Oil

Guides on adding engine oil and recommended types.

Troubleshooting Common Issues

Engine Starting and Performance Problems

Faults related to engine not starting, starting issues, or low power.

Indicator Lamp and System Malfunctions

Issues with warning lamps, FI, ABS, and neutral indicator.

Electrical System and Battery Faults

Technical Data

Engine Specifications and Tightening Torques

Capacities and Chassis Specifications

Fork and Shock Absorber Details

Chassis Tightening Torques

KTM 690 Duke 2017 Specifications

General

Displacement	690 cc
Compression Ratio	12.7:1
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Transmission	6-speed
Starter	Electric starter
Lubrication	Forced oil lubrication with 2 oil pumps
Front Suspension	WP upside-down Ø 43 mm
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	835 mm
Ground Clearance	192 mm
Wheelbase	1, 466 mm
Fuel Capacity	14 liters
Dry Weight	148.5 kg
Engine Type	Single-cylinder, 4-stroke
Torque	74 Nm @ 6, 500 rpm
Frame	Chromium-Molybdenum steel trellis frame
Rear Suspension	WP monoshock
Front Brake	Brembo four-piston radial fixed caliper, 320 mm disc
Rear Brake	Single 240 mm disc, Brembo single-piston caliper
ABS	Bosch 9M+ two-channel ABS (disengageable)
