KTM 690 Duke 2018 User Manual (English)

Other manuals for KTM 690 Duke 2018

Questions and Answers:

C
Charles OchoaAug 18, 2025
Why is my KTM 690 Duke 2018 engine overheating?
- K
  Kevin WilsonAug 18, 2025
  Your KTM Motorcycle engine might be overheating due to several reasons. Check if there's too little coolant in the cooling system, inspect for leaks, and verify the coolant level. Dirty radiator fins can also cause overheating, so clean them. Other potential issues include foam formation in the cooling system (in which case you should drain, fill, and bleed the system), a buckled or damaged radiator hose (replace if necessary), a faulty thermostat (check it), a blown fuse 4 (replace it), or a defect in the radiator fan system (check it).
H
hamiltoncrystalAug 20, 2025
What to do if KTM 690 Duke 2018 engine turns over but doesn't start?
- M
  Mario JohnsonAug 20, 2025
  If your KTM Motorcycle engine turns over but doesn't start, consider these possible causes: an operating error (ensure you follow the correct start procedure), a blown fuse 3 (replace it), a disconnected fuel hose connection (connect it), or a defect in the fuel injection system.
R
rwhitakerAug 23, 2025
Why does my KTM 690 Duke 2018 have high oil consumption?
- B
  Benjamin TateAug 23, 2025
  High oil consumption in your KTM Motorcycle can stem from a few issues. A bent engine vent hose can cause this, so ensure it's properly routed without bends, replacing it if needed. Also, check the engine oil level, as a level that is too high can contribute to this problem. Lastly, using engine oil that is too thin (low viscosity) can also lead to high oil consumption, so change the engine oil and filter, and clean the oil screens.
C
Courtney CraigAug 25, 2025
What to do if my KTM 690 Duke 2018 Motorcycle engine dies while riding?
- J
  Jennifer LangAug 26, 2025
  If your KTM Motorcycle engine dies during a trip, it could be due to a lack of fuel, in which case you should refuel. It could also be caused by blown fuses 1, 2, or 3; replace them if necessary.
S
Stephen McclureAug 28, 2025
What to do if my KTM 690 Duke 2018 Motorcycle engine won't crank?
- R
  richardssusanAug 28, 2025
  If your KTM Motorcycle engine won't crank when you press the electric starter, there are several potential causes. It could be due to an operating error, so ensure you are following the correct start procedure. The battery might be discharged, requiring a recharge and an open-circuit current check. Additionally, check fuses 1, 2, or 3 and the main fuse, replacing them if blown. Finally, verify the ground connection is properly connected.
N
Nina HansenAug 30, 2025
Why is the ABS indicator lamp on in my KTM 690 Duke 2018 Motorcycle?
- H
  Heather OrtizAug 30, 2025
  The ABS indicator lamp in your KTM Motorcycle might light up due to several reasons. It could be that the ABS fuse is blown, so replace it. Another cause could be a large difference in wheel speeds between the front and rear wheels; in this case, stop the vehicle, switch off the ignition, and start it again. A malfunction in the ABS could also be the reason.
S
Sandra ClineSep 1, 2025
What does it mean when the malfunction indicator lamp lights up on my KTM 690 Duke 2018 Motorcycle?
- K
  Kristin CookSep 1, 2025
  If the malfunction indicator lamp lights up or flashes on your KTM Motorcycle, it indicates a defect in the fuel injection system.
M
meganmackSep 4, 2025
How to fix a discharged battery on my KTM 690 Duke 2018 Motorcycle?
- P
  Pamela ThompsonSep 4, 2025
  A discharged battery on your KTM Motorcycle may be due to the ignition not being switched off when the vehicle was parked; in this case, recharge the battery. Another reason could be that the battery is not being charged by the alternator; you should check the charging voltage and the open-circuit current.
J
Jean WheelerSep 7, 2025
Why aren't the headlight and parking light working on my KTM 690 Duke 2018?
- T
  Terri RhodesSep 7, 2025
  If the headlight and parking light are not functioning on your KTM Motorcycle, the fuse 6 may be blown. Replace the fuse.
J
Jasmine GarnerSep 9, 2025
What causes the turn signal, brake light, and horn to stop working on my KTM 690 Duke 2018?
- G
  Gabrielle BlackwellSep 10, 2025
  If the turn signal, brake light, and horn are not functional on your KTM Motorcycle, it is possible that fuse 5 is blown. Replace the fuse.

KTM 690 Duke 2018 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	690 cc
Torque	74 Nm @ 6, 500 rpm
Compression Ratio	12.7:1
Transmission	6-speed
Fuel System	Electronic fuel injection
Cooling System	Liquid cooled
Front Suspension	WP USD Ø 43 mm
Rear Suspension	WP Monoshock
Seat Height	835 mm
Dry Weight	148.5 kg
Fuel Capacity	14 liters
Bore x Stroke	105 mm x 80 mm
Starter	Electric starter
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Power	73 hp (54 kW) @ 8, 000 rpm
Front Brake	Brembo four-piston radial caliper, 320 mm disc
Rear Brake	Brembo single-piston floating calliper, brake disc Ø 240 mm
ABS	Bosch 9M+ Two Channel ABS
Frame	Chromium-Molybdenum steel trellis frame, powder-coated

Summary

Means of Representation

Symbols Used

Explains various symbols used in the manual.

Formats Used

Explains typographical formats like proprietary names and brands.

Safety Advice

Intended Use

Defines the intended use of the vehicle and restrictions.

Degrees of Risk and Symbols

Defines danger, warning, and note symbols with associated risks.

Safe Operation

Safety advice regarding rider fitness and potential dangers.

Important Notes

Manufacturer and Implied Warranty

Conditions for warranty coverage and voiding it.

Service

Importance of proper service, care, and tuning for operation and wear.

View of Vehicle

View of Vehicle, Front Left

Illustrates and labels key components of the motorcycle from the front left.

View of Vehicle, Rear Right Side

Illustrates and labels key components of the motorcycle from the rear right.

Serial Numbers

Chassis Number

Location of the chassis number on the steering head.

Key Number

Where to find the key number and its importance for ordering spare keys.

Controls

Clutch Lever

Location and operation of the clutch lever.

Hand Brake Lever

Location and operation of the hand brake lever for the front brake.

Emergency OFF Switch

Operation of the emergency OFF switch (on/off states).

Ignition/Steering Lock

States of the ignition/steering lock (off, on, locked).

Combination Instrument

Overview of the instrument cluster and its function areas.

Indicator Lamps

Explains the function of various indicator lamps on the instrument panel.

TC/ABS

How to switch TC and ABS on/off and select ABS modes.

Preparing for Use

Advice on Preparing for First Use

Safety advice on rider fitness, protective clothing, tires, and wheels.

Running in the Engine

Guidelines for engine speed during the running-in phase.

Riding Instructions

Starting the Vehicle

Safety warnings and step-by-step procedure for starting the engine.

Shifting, Riding

Warnings about abrupt load changes, downshifting, ignition key position, and adjustments.

Applying the Brakes

Warnings about moisture/dirt, spongy brake pressure, and overheating.

Service Schedule

Required Work

Table detailing required maintenance tasks and their intervals.

Recommended Work

Table detailing recommended maintenance tasks and their intervals.

Tuning the Chassis

Adjusting the Spring Pretension of the Shock Absorber

Procedure for adjusting shock absorber spring preload and guidelines.

Service Work on the Chassis

Cleaning the Chain

Warnings about oil/grease on tires/discs and cleaning procedure.

Checking the Chain Tension

Warnings about incorrect chain tension and how to check it regularly.

Checking the Chain, Rear Sprocket, and Engine Sprocket

How to check chain, sprockets for wear and when to change the drivetrain kit.

Brake System

Antilock Brake System (ABS)

Explanation of ABS unit, sensors, and warnings about vehicle changes.

Adding Front Brake Fluid

Procedure for checking and adding front brake fluid.

Checking the Free Travel of Foot Brake Lever

Warning about no free travel causing rear brake pressure buildup.

Wheels, Tires

Removing the Front Wheel

Preparatory and main work steps for removing the front wheel.

Installing the Rear Wheel

Procedure for checking hub dampers, wheel bearing, and installing the rear wheel.

Checking the Tire Condition

Warnings about tire bursts, tread patterns, non-approved tires, and new tires.

Electrical System

Removing the Battery

Safety warnings for battery acid and gases, and procedure for removal.

Changing the Main Fuse

Warnings about incorrect fuses and procedure for changing the main fuse.

Changing the Headlight Bulb

Notes on reflector care and procedure for changing the headlight bulb.

Cooling System

Checking the Antifreeze and Coolant Level

Safety warnings for hot coolant and environmental hazards.

Filling/Bleeding the Cooling System

Safety warnings for coolant and procedure for filling/bleeding.

Tuning the Engine

Adjusting the Basic Position of the Shift Lever

Procedure for adjusting the shift lever's basic position.

Traction Control (Optional) (TC)

Function of TC and how it's controlled via menus.

Service Work on the Engine

Checking the Engine Oil Level

Procedure for checking engine oil level at normal operating temperature.

Changing the Engine Oil and Oil Filter, Cleaning the Oil Screens

Safety warnings for hot oil and environmental hazards.

Cleaning, Care

Cleaning the Motorcycle

Warnings about pressure cleaners and environmental hazards.

Checks and Maintenance Steps for Winter Operation

Precautions against road salt and cleaning steps for winter.

Storage

Actions for storing the motorcycle for a longer period.

Preparing for Use After Storage

Steps to take the motorcycle out of storage and prepare it.

Troubleshooting

Faults

Table listing faults, possible causes, and actions to resolve them.

Technical Data

Engine

Specifications related to the engine design, displacement, bore, etc.

Engine Tightening Torques

Table listing screws and their specified tightening torques.

Capacities

Table listing capacities for engine oil, coolant, and fuel.

Electrical System

Specifications for battery, fuses, and headlight.

Substances

Brake Fluid DOT 4 / DOT 5.1

Standard, guidelines, and recommended suppliers for brake fluid.

Coolant

Guidelines for coolant use and antifreeze protection level.

Auxiliary Substances

Chain Cleaner

Recommended supplier and product for chain cleaner.

Fuel Additive

Recommended supplier and product for fuel additive.

Standards

JASO T903 MA

Explanation of the JASO T903 MA standard for motorcycle engines.

Index of Special Terms

Definitions of Special Terms

Definitions of special terms used in the manual.

List of Abbreviations

List of common abbreviations and their meanings.

List of Symbols

Red Symbols

Explains red symbols indicating immediate intervention required.

Yellow and Orange Symbols

Explains yellow/orange symbols for prompt intervention and driving aids.
