KTM 690 DUKE EU User Manual (English)

Questions and Answers:

L
Lynn BallAug 17, 2025
What to do if my KTM Motorcycle engine turns but does not start?
- C
  cynthiarangelAug 18, 2025
  If your KTM Motorcycle engine turns but doesn't start, it might be due to an operating error, a blown fuse 3, a disconnected fuel hose coupling, a defect in the fuel injection system, opening the throttle while starting, a very dirty air filter, or a very dirty fuel filter. When starting, do not open the throttle and carry out the start procedure. Reconnect the coupling of the fuel hose connection. Remove and install the air filter. You can check the fuel pressure.
W
walkerangelaAug 20, 2025
What to do if my KTM 690 DUKE EU engine does not crank?
- O
  orobinsonAug 20, 2025
  If your KTM Motorcycle engine does not crank when you press the electric starter button, it could be due to an operating error. In that case, carry out the start procedure. It may also be because the battery is discharged (recharge it), fuse 1, 2, or 3 is blown (change the fuses), the main fuse is burned out (change the main fuse), or there is no ground connection (check the ground connection).
J
Jeremy TaylorAug 23, 2025
Why does my KTM 690 DUKE EU Motorcycle engine die during the trip?
- A
  alexander66Aug 23, 2025
  Your KTM Motorcycle engine may die during the trip due to a lack of fuel, so refuel. It could also be because fuse 1, 2, or 3 is blown; in this case, change the fuses.
H
Heather MyersAug 26, 2025
Why does my KTM 690 DUKE EU have high oil consumption?
- J
  Jennifer WilliamsAug 26, 2025
  High oil consumption in your KTM Motorcycle could be due to the engine oil level being too high, so check the engine oil level. Another reason could be that the engine oil is too thin (low viscosity). In this case, change the engine oil and filter, and clean the oil screens.
R
Regina MccallAug 27, 2025
What to do if the FI warning lamp lights/flashes on my KTM 690 DUKE EU?
- R
  ryanwilliamsAug 27, 2025
  If the FI warning lamp (MIL) lights or flashes on your KTM Motorcycle, it indicates a defect in the fuel injection system. You should read out the fault memory using the KTM diagnostics tool.
J
jperezAug 30, 2025
How to fix a KTM Motorcycle that only turns if the clutch lever is drawn?
- L
  Lee EvansAug 30, 2025
  If your KTM Motorcycle only turns when the clutch lever is drawn, it's likely because the vehicle is in gear. Shift gear to neutral. It might also happen if the vehicle is in gear and the side stand is folded out. Again, shift gear to neutral.
J
Jessica StoutSep 1, 2025
What causes the headlight and parking light to stop functioning on my KTM Motorcycle?
- L
  Leslie CaldwellSep 2, 2025
  If the headlight and parking light are not functioning on your KTM Motorcycle, it is possible that fuse 6 is blown. In this case, change the fuses.
M
Melinda PetersenSep 4, 2025
What causes turn signal, brake light, and horn to not work on a KTM 690 DUKE EU?
- V
  vincent86Sep 4, 2025
  If the turn signal, brake light, and horn are not functional on your KTM Motorcycle, it is possible that fuse 5 is blown. In that case, change the fuses.
S
Sara ContrerasSep 6, 2025
Why is my KTM Motorcycle battery discharged?
- H
  hughesjasonSep 6, 2025
  Your KTM Motorcycle battery may be discharged because the ignition was not switched off when the vehicle was parked, so recharge the battery. It could also be that the battery is not charged by the alternator.
K
Kristina AndersonSep 9, 2025
What causes the idle indicator lamp to not light up on my KTM 690 DUKE EU?
- S
  Sandra FlynnSep 9, 2025
  If the idle indicator lamp does not light up when the transmission is in neutral on your KTM Motorcycle, the gear position sensor may not be programmed. In this case, read out the fault memory using the KTM diagnostics tool.

KTM 690 DUKE EU Specifications

General

Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Tyre	120/70 ZR 17
Rear Tyre	160/60 ZR 17
Engine Type	Single-cylinder, 4-stroke
Fuel System	Electronic fuel injection
Cooling	Liquid cooled
Front Suspension	WP USD Ø 43 mm
Front Brake	Brembo four-piston radial fixed caliper, 320 mm brake disc
Rear Brake	Brembo single-piston floating caliper, 240 mm brake disc
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Fuel Tank Capacity	14 l

Summary

Safety Advice

Safe Operation

Covers safe operation, including alcohol, exhaust gases, and hot components.

Protective Clothing

Emphasizes the importance of wearing appropriate protective clothing.

Controls

Clutch Lever Operation

Describes the location and hydraulic operation of the clutch lever.

Hand Brake Lever Adjustment

Details the location and adjustment of the hand brake lever.

Throttle Grip

Specifies the location of the throttle grip on the handlebar.

Emergency OFF Switch

Details the location and function of the emergency OFF switch.

Electric Starter Button

Specifies the location and operation of the electric starter button.

Ignition and Steering Lock

Describes the location and operation of the ignition and steering lock.

Combination Instrument Functions

Covers instrument overview, buttons, lamps, display modes, and settings.

Filler Cap Operation

Provides safety warnings and steps for opening and closing the fuel filler cap.

Shift Lever Adjustment

Details the location and adjustment of the shift lever.

Foot Brake Lever Adjustment

Specifies the location and adjustment of the foot brake lever.

Preparing for Use

Advice on First Use

Covers crucial initial advice, including safety, clothing, and tires.

Engine Running-in Procedure

Provides guidelines and recommended speeds for the engine break-in period.

Vehicle Loading Guidelines

Warns about handling changes and risks associated with vehicle loading.

Riding Instructions

Pre-Ride Checks and Care

Lists essential checks and vehicle care before riding.

Starting the Engine

Details the procedure and safety precautions for starting the motorcycle.

Starting Off Procedure

Explains the steps for moving off from a standstill.

Shifting Gears and Riding

Provides guidance on gear shifting and general riding techniques.

Applying the Brakes

Offers instructions and warnings on proper brake application.

Stopping and Parking

Details safe procedures for stopping and parking the motorcycle.

Refueling Procedure

Covers safety precautions and steps for refueling the motorcycle.

Service Schedule

Maintenance Schedule Overview

Presents a table of maintenance intervals and required tasks.

Tuning the Chassis

Adjusting Fork Compression Damping (Duke R)

Provides instructions on adjusting the fork's compression damping.

Adjusting Fork Rebound Damping (Duke R)

Details how to adjust the fork's rebound damping.

Adjusting High-Speed Compression Damping (Duke R)

Guides on adjusting the shock absorber's high-speed compression.

Adjusting Low-Speed Compression Damping (Duke R)

Instructs on adjusting the shock absorber's low-speed compression.

Adjusting Rebound Damping (Duke R)

Details how to adjust the shock absorber's rebound damping.

Adjusting Spring Preload

Explains how to adjust the shock absorber's spring preload.

Service Work on the Chassis

Adjusting Chain Tension

Provides steps for adjusting the drive chain tension.

Brake System

ABS System Overview

Explains the ABS system, its components, and functional limitations.

Adjusting Hand Brake Lever

Provides instructions for adjusting the hand brake lever's position.

Checking Front Brake Fluid Level

Explains how to check and add front brake fluid.

Adding Front Brake Fluid

Provides the procedure for adding front brake fluid.

Adjusting Foot Brake Lever Position

Details how to adjust the basic position of the foot brake lever.

Checking Rear Brake Fluid Level

Explains how to check and add rear brake fluid.

Adding Rear Brake Fluid

Provides the procedure for adding rear brake fluid.

Wheels and Tires

Removing the Front Wheel

Step-by-step instructions for removing the front wheel.

Tuning the Engine

Setting Engine Characteristics

Explains how to select different engine performance modes.

Service Work on the Engine

Checking Engine Oil Level

Explains how to check the engine oil level at operating temperature.

Changing Engine Oil and Filter

Provides the procedure for changing engine oil, filter, and cleaning screens.

Troubleshooting

Troubleshooting Guide

Lists common faults, possible causes, and recommended actions.

Blink Code

FI Warning Lamp Blink Codes

Explains the diagnostic blink codes indicated by the FI warning lamp.

Technical Data

Engine Specifications

Provides detailed specifications for the motorcycle's engine.

Engine Tightening Torques

Lists torque values for various engine assembly fasteners.

Chassis Tightening Torques

Lists torque values for various chassis fasteners.
