LIST OF SYMBOLS 30
377
30.1 Red symbols
Red symbols indicate an error condition that requires immediate intervention.
The oil pressure warning lamp lights up red – The oil pressure is too low. Stop immediately,
taking care not to endanger yourself or other road users in the process, and switch off the
engine.
30.2 Yellow and orange symbols
Yellow and orange symbols indicate an error condition that requires prompt intervention. Active driving aids are
also represented by yellow or orange symbols.
Malfunction indicator lamp lights up yellow – The OBD has detected a malfunction in the
vehicle electronics. Come safely to a halt, and contact an authorized KTM workshop.
ABS warning lamp lights up/flashes yellow – Status or error messages relating to ABS. The
ABS warning lamp flashes if the ABS mode Offroad is enabled.
TC indicator lamp lights up/flashes yellow – MTC ( p. 317) is not enabled or is currently
intervening. The TC indicator lamp also lights up if a malfunction is detected. Contact an
authorized KTM workshop. The TC indicator lamp flashes if MTC makes an active intervention.
The cruise control system indicator lamp (optional) lights up yellow – The cruise control sys-
tem function is switched on, but cruise control is not activated.
The general warning lamp lights up yellow – A note/warning note on operating safety has been
detected. This is also shown in the display.
