TECHNICAL DATA 20
121
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw for throttle grip M6 5 Nm (3.7 lbf ft)
Screw, ball joint of push rod on
foot brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, clutch assembly on handle-
bar
M6 5 Nm (3.7 lbf ft)
Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft)
Screw, front brake assembly on
handlebar
M6 5 Nm (3.7 lbf ft)
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, front fender M6 6 Nm (4.4 lbf ft)
Screw, ignition coil M6 6.4 Nm (4.72 lbf ft)
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, tank spoiler on radiator M6 6 Nm (4.4 lbf ft)
Start number plate screw M6 4 Nm (3 lbf ft)
Throttle cable wire on carburetor
cover
M6x0.75 3 Nm (2.2 lbf ft)
Nut, rim lock M8 10 Nm (7.4 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, engine brace M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, engine sprocket cover M8 15 Nm (11.1 lbf ft)
Screw, foot brake lever stop M8 20 Nm (14.8 lbf ft)
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, rear brake caliper M8 18 Nm (13.3 lbf ft)
Loctite
®
243™
Screw, rear sprocket M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Screw, subframe M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Screw, top triple clamp M8 17 Nm (12.5 lbf ft)
Steering stem clamp screw M8 20 Nm (14.8 lbf ft)
Engine carrying screw M10 45 Nm (33.2 lbf ft)
Nut, foot brake lever M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
