SERVICE WORK ON THE CHASSIS 13

245

13.28 Installing the windshield

F02055-10

–

Position windshield

1

in upper recess

A

or in lower

recess

B

.

–

Mount and tighten screw

2

.

Guideline

Remaining screws,

chassis

M5 5 Nm (3.7 lbf ft)
