ENGLISH
ASSEMBLY 5
9
504074-01
Assembly
– Install the lower triple clamp (see Owner's Manual).
Fork offset
504075-01
Info
Using the factory triple clamp, the offset of the fork (center of fork legs – center of steering head bea-
ring) can be set to either 20 or 22 mm. This enables the handling to be adapted even better to the
race tracks. The offset that is set can be seen from marking
A
.
–
20 mm offset
A
.
The number 20 is visible.
–
22 mm offset
B
.
The number 20 is not visible.
