SETUP 2
11
F01630-10
–
Press the spring with special tool
bl
.
Footrest spring plier (79029083000)
The special tool is applied to area
D
on the footrest.
–
Mount pin
bm
.
F01631-10
–
Mount the washer and splint
bn
.
R00757-10
Left footrest (All XC‑F models)
– Position the left footrest and pin.
Info
Only insert the pin to the extent that the spring can
still be mounted.
K00688-10
– Position spring as shown.
Spring
E
engages in area
F
.
