KTM F8201V5 - 3.8 Removing the air filter box cover

3 WORK
18
F01533-10
–
Mount and tighten screw
1
.
Guideline
Screw, rear seat fix-
ing
M6 10 Nm (7.4 lbf ft)
3.8 Removing the air filter box cover
Condition
The air filter box cover is secured.
– Remove the seat. ( p. 17)
F01588-10
–
Remove screw
1
.
F01588-11
–
Pull off the air filter box cover in area
A
sideways and
take off toward the front.
F01589-10
Condition
The air filter box cover is not secured.
–
Pull off the air filter box cover in area
A
sideways and
take off toward the front.
