Kuat NV BASE 2.0 - Adjust Front Cradle for Fit; Fasten Rear Tire Strap

8
NOTE:
7RDGMXVWIRUELF\FOHðWLVVXHVORRVHQWKH
front cradle bolt with an 8mm allen wrench (Do not
fully remove the bolt). Once loose, move the cradle to
one of three positions; up, center, or down. Tighten
the bolt to secure the cradle in position.
Failure to re-tighten bolt can lead to loss of bike.
STEP 3. Feed the rear tire strap through the
rear tire and behind the tire retention tab, then pull
through the ratchet pawl until the rear tire is secure.
NOTE: Failure to properly feed and tighten the
strap can lead to loss of bike.
NOTE. To adjust for bicycle fit issues, loosen the
front cradle bolt with an 8mm Allen wrench (Do not
fully remove the bolt). Once loose, move the cradle
to one of three positions; up, center, or down.
Tighten the bolt to secure the cradle in position.
Tire scoop will need to be adjusted into the down position to
accommodate 50” wheelbases.
