Kuat PIVOT - Swing-Away Operation

Swing-Away Operation:
1 Pull down on the toggle clamp.
3 Pivot the top arm out 90 degrees and secure with the saftey pin.
2 Unlatch safety gate and remove pin.
1
2
3
Prior to performing the swing away operation ensure the vehicle is in park.
