2 SPECIFICATIONS
SPECIFICATIONS
SPECIFICATION TABLE
Model B3300SUHSD
PTO power* kW (HP) 18.6 (25.0)
Engine
Maker KUBOTA
Model V1505-E3-D24H
Type Indirect Injection, Vertical, water-cooled, 4 cycle diesel
Number of cylinders 4
Bore and stroke mm (in.) 78 x 78.4 (3.1 x 3.1)
Total displacement cm (cu.in.) 1498 (91.5)
Engine gross power* kW (HP) 24.6 (33.0)
Rated revolution rpm 2700
Low idling revolution rpm 1000 to 1100
Maximum torque N-m (ft-lbs) 91 (67)
Battery 12 V, RC : 79 min, CCA : 433 A
Capacities
Fuel tank L (U.S.gals.) 31 (8.1)
Engine crankcase
(with filter)
L (U.S.qts.) 5.4 (5.7)
Engine coolant L (U.S.qts.) 4.5 (4.7)
Transmission case L (U.S.gals.) 14.5 (3.83)
Tires
Front
Farm
7-12
Industry
23 x 8.50-14
Rear 12.4-16 12.4-16
Dimensions
Overall length
(without 3P)
mm (in.) 2520 (99.2) 2510 (98.8)
Overall width mm (in.) 1365 (53.7)
Overall height
(with ROPS)
mm (in.) 2245 (88.4) 2235 (88.0)
Wheel base mm (in.) 1696 (66.8)
Min. ground
clearance
mm (in.) 370 (14.6)
Tread
Front mm (in.) 935 (36.8) 905 (35.6)
Rear mm (in.) 1050 (41.3)
Weight (with ROPS) kg (lbs.) 800 (1764) 810 (1786)
Traveling
system
Clutch Dry single plate
Steering Integral type power steering
Transmission
Main-hydrostatic transmission,
3 range gear shift (3 forward, 3 reverse)
Brake Wet disk type
Min. turning radius
(with brake)
m (feet) 2.4 (7.9)
