Kubota BX24 Workshop Manual

4-S2
BX24, RCK54(P)-23BX, RCK60B-23BX, LA240, BT601, WSM
STEERING
2. SERVICING SPECIFICATIONS
POWER STEERING BODY
W1013874
STEERING CYLINDER
W1013973
Item Factory Specification Allowable Limit
Relief Valve Operating
Pressure
8.33 to 8.83 MPa
85.0 to 90.0 kgf/cm
2
1209 to 1280 psi
–
Steering Cylinder I.D. 40.000 to 40.062 mm
1.57480 to 1.57724 in.
40.100 mm
1.57874 in.
Piston Rod to Guide Clearance 0.020 to 0.070 mm
0.00079 to 0.00276 in.
0.200 mm
0.00787 in.
KiSC issued 08, 2019 A

Kubota BX24 Specifications

General

Engine Power	23 hp (17.2 kW)
Transmission Type	Hydrostatic
Brakes	Wet disc
Power Steering	Yes
Rear PTO	540 RPM
Hydraulic System Type	Open center
3-Point Hitch	Category I
Engine Type	Diesel
Wheelbase	55.1 inches
Width	44.5 inches
Height	85.4 inches
PTO Power	17.7 hp
Gears	2-range (Hi/Lo)
