33SPECIFICATIONS
ENGLISH
A Flywheel type is SAE clutch No. 7-1/2 or its equivalent.
A Flywheel housing type is SAE No. 4 or its equivalent.
A Continuous will operate at the stated rating continuously and have a 10% overload capability for one hour in 12 hours.
A Standby will operate at the stated full rating for one hour in 12 hours. No overload capacity is specified for this rating.
A Specifications are subject to change without notice.
Model V2403-M-E3BG
Type Vertical, water-cooled, 4-cycle diesel engine
Number of cylinders
4
Bore and stroke
mm (in.)
87 x 102.4
(3.47 x 4.04)
Total displacement
L (cu.in.)
2.434
(148.53)
Combustion chamber Spherical Type (E-TVCS)
SAE NET Continuous kW / rpm
H.P. (SAEJ1349) (HP / rpm)
22.1 / 1800 (29.6 / 1800)
18.8 / 1500 (25.2 / 1500)
SAE NET Standby kW / rpm
H.P. (SAEJ1349) (HP / rpm)
26.5 / 1800 (35.5 / 1800)
22.0 / 1500 (29.5 / 1500)
Maximum bare speed rpm 1800 / 1500
Order of firing 1-3-4-2
Direction of rotation Counter-clockwise (viewed from flywheel side)
Injection pump Bosch Type mini pump
Governor Electronic Governor
Injection pressure Mpa (kgf/cm , psi) 13.73 (140, 1991)
Injection timing (Before T.D.C.) 0.27 rad (15.25 )
Compression ratio 23.2
Fuel Diesel Fuel No.2-D (ASTM D975)
Lubricant (API classification) above CF
Dimension mm (in.)
(length x width x height)
700.6 x 490 x 684
(27.6 x 19.3 x 26.9)
Dry weight (BB Spec.) kg (lbs.) 199 (438.7)
Starting system Cell starter (with glow plug)
Starting motor 12 V, 2.0 kW
Charging generator 12 V, 480 W
Recommended battery capacity 12 V, 100 to 120 AH, equivalent
