7. Tightening Torque
7 . 1 Specific Torque
No.
Assemble (A) to (B)
Part Name Size Q'ty
Tightening
Torque
N
・m(kgf・cm
）
PARTS (A) PARTS (B)
1 EXCITOR STATOR HOUSING BOLT M5x40 4
3.0- 4.9
( 31- 49)
2 REAR HOUSING FRONT HOUSING BOLT,12 M12x220 4
29.5-32.3
(301-329)
3 STAY,RIGHT,LEFT
HOUSING,REAR,FRONT
BOLT M10x30 8
19.7-24.5
(201-249)
4 ROTAR ENGINE BOLT M10x1.25x30 4
40.7-49.5
(416-504)
5 FAN,COOLING ENGINE BOLT M8x25 6
9.9-14.7
(101-149)
6
HOUSING
(GENARATOR ASSY)
ENGINE BOLT,10 M10x1.25x25 8
19.7-24.5
(201-249)
7 STAY,ENGINE ENGINE BOLT,10 M10x1.25x25 8
28.5-34.3
(291-349)
8 LEAD ENGINE BOLT,10 M10x1.25x20 2
28.5-34.3
(291-349)
9 PLUG,DRAIN SOCKET PLUG,DRAIN M12x1.25x13 3
39.3-49.0
(401-499)
10 PIPE,EXHAUST
ENGINE
PIPE,EXHAUST
NUT,8 M8 6
17.7-21.5
(181-219)
11 LEAD SWITCH,MAGNETIC NUT M8 1
9.9-11.7
(101-119)
12 TERMINAL,BATTERY BATTERY NUT M6 2
5.0- 6.0
(51- 61)
13 LEAD TERMINAL,BATTERY BOLT M8 2
6.9- 8.8
( 71- 89)
14 HARNESS,WIRE PLUG,GLOW NUT M4 1
1.0- 1.7
( 11- 17)
15 HARNESS,WIRE OIL PRESS SWITCH BOLT M4x8 1
1.4- 1.9
( 15- 19)
16 STRAINER,FUEL STAY,BONNET(RIGHT) BOLT,8 M8x65 1
17.7-21.5
(181-219)
17 BOLT,STUD 8 PLATE,INST NUT,8 M8 3
13.5-15.3
(138-156)
18 SWITCH,STARTER PANEL,OPERATION NUT 1
4.0- 6.0
( 41- 61)
19 PLUG,DRAIN VALVE PLUG,DRAIN 1
13.0-15.0
(133-152)
20 PANEL DOOR,FRONT NUT,5 M5 2
2.0- 2.9
( 21- 29)
21 SWITCH GUARD NUT Resin(PF1/8) 2
0.6- 1.0
( 7- 10)
