Kubota DG972 E2 - 8 Center of Gravity

1-12
8. CENTER OF GRAVITY
1. With standard flywheel and rear-end plate
2. With SAE flywheel and flywheel housing
NOTE
• Cooling water and lubricating oil weight is not included in above engine weight.
Model
Dry weight
kg (lb)
Center of gravity
X mm (in) Y mm (in) Z mm (in)
WG752 61.7 (136) 2 (0.08) 64 (2.52) 171 (6.73)
WG/DG972 72 (159) −25.5 (−1.00) 73.3 (2.89) 179.5 (7.07)
Model
Dry weight
kg (lb)
Center of gravity
X mm (in) Y mm (in) Z mm (in)
WG752 89 (196.2) 1 (0.04) 47 (1.85) 188 (7.4)
DG972 95.4 (210) −10 (−0.39) 28 (1.1) 207 (8.15)
