PARTS
OM 0313QH-A 27
MALE QUICK HITCH AND SUBFRAME – L2180
REF. DESCRIPTION QTY PART # CODE
1 Male quick hitch ass'y 1 70000-02721 666441
2 Front subframe 1 70000-02719 666436
3 Rear subframe 1 70000-02718 666424
4 Subframe bracket 1 70000-02723 666444
5 Cylinder support 1 70000-02724 666455
6 "T" pin Ø1 3/4" 2 70000-02725 666456
7 Cylinder Ø2" x 5" & pins 1 70000-02740 3900029
Pin 3/4" x 2 1/2" 70001-00795 665235
Cotter pin 3/16" x 1 1/4" 1 O/L O/L
Seal kit 1 70001-00872 665434
8 "T" pin Ø3/4" 1 70000-02726 666457
9 Parking stand extension 1 70000-02728 666459
10 Hose support 4 70060-01609 658489
11 Pivot bushing 2 70000-02727 666458
12 Pin Ø1/2" x 3" 1 70000-02729 666460
13 Compression spring 1 70000-02717 657658
14 Elbow 90°, 3/8 NPT 1 70060-70380 655314
15 Flow restrictor 0.063" 1 70000-02741 3900112
16 Hose 1/4" x 90", 3/8 NPT 2 70060-01746 659011
17 Blue identification ring 2 70060-01727 658205
18 Red identification ring 2 70060-01726 658204
19 Quick coupler 3/8 NPT 2 70060-02659 2600070
20 Dust plug 2 70060-02660 2600071
21 Bolt hex. 1 1/8" NC x 4" lg., gr.5, PTD 2 O/L O/L
22 Flatwasher Ø1 1/4", PTD 2 O/L O/L
23 Lockwasher 1 1/8", PTD 2 O/L O/L
24 Nylon insert locknut 1 1/8" NC, PTD 2 O/L O/L
25 Bolt hex. 1/2" NC x 1 3/4" lg., gr.5, PTD 3 O/L O/L
26 Lockwasher 1/2", PTD 4 O/L O/L
27 Nylon insert locknut 1/2" NC, PTD 4 O/L O/L
28 Bolt hex. M14 x 1.5 x 40mm lg., gr.8.8, PTD 4 70060-70433 0200040
29 Int. teeth lockwasher 14mm, PTD 4 70060-70432 1300006
30 Bolt hex. 3/4" NC x 2 1/4" lg., gr.5, PTD 4 O/L O/L
31 Flatwasher Ø13/16", PTD 8 O/L O/L
32 Lockwasher 3/4", PTD 4 O/L O/L
33 Nylon insert locknut 3/4" NC, PTD 4 O/L O/L
34 Bolt hex. 3/8" NC x 1 1/4" lg., gr.5, PTD 2 O/L O/L
35 Lockwasher 3/8", PTD 2 O/L O/L
36 Nut hex. 3/8" NC, PTD 2 O/L O/L
37 Bolt hex. 1/2" NC x 1 1/4" lg., gr.5, PTD 1 O/L O/L
To Next Page
