PARTS
OM 0313QH-A
28
MALE QUICK HITCH AND SUBFRAME – L2180
REF. DESCRIPTION QTY PART # CODE
38 Pipe pin 3/8" x 2 1/2", PTD 2 70060-70431 1900008
39 Spring pin Ø1/8" x 1" lg. 1 O/L O/L
40 Spring pin Ø3/16" x 1 3/4" lg. 1 O/L O/L
41 Hairpin Ø 1/8" x 2 9/16" lg. PTD 1 70060-00000 1800004
42 Support intermédiaire 1 70060-01922 666745
43 Installation plate for mid support 2 70060-01923 666746
44 Spacer for mid support 1 70060-01924 666747
45 Pin Ø1 1/4" x 5 3/4" lg. PTD 2 70060-01931 4600016
46 Lockwasher16mm, PTD 4 70060-70434 1200021
47 Flatwasher Ø11/16" int. PTD 4 O/L O/L
48 Lock pins 1/4" round PTD 2 70060-01929 1900006
49 Spring pinØ5/16" x 3" 2 O/L O/L
50 Bolt hex. M16 x 1.5 x 55mm lg. PTD 4 70060-01935 0200108
To Next Page
