Kubota M110GX Workshop Manual

5 2015.11 • Wrong Correction
Additional line was drawn in the electric circuit because a wiring
between battery and starter was missed in the previouse circuit.
Reference page: The diagram at the end of the book.
8-M1,
8-M2,
8-M3,
8-M4,
8-M28,
8-M33
• Wrong Correction
Correct:
Black/White wiring connects to terminal 5 of main key switch.
Reference page: The diagram at the end of the book.
8-M1,
8-M2,
8-M3,
8-M4,
8-S93,
8-S94
• Wrong Correction
Terminal no. of hand throttle lever sensor was corrected.
Reference page: The diagram at the end of the book. 8-M10
• Wrong Correction
Wiring color between shuttle rotation sensor and main ECU was
corrected.
Reference page: The diagram at the end of the book. 8-M10
• Wrong Correction
Electric circuit for front wiper motor was corrected.
Reference page: The diagram at the end of the book. 8-M11
• Wrong Correction
Correct:
(7) Glow Relay, (8) Starter Relay 8-M19
• Wrong Correction
Correct:
(1) Turn Signal Relay LH, (4) Turn Signal Relay Relay RH 8-M26
• Wrong Correction
E-R30 Unload Solenoid --> E-H30 Unload Solenoid 8-S12
• Wrong Correction
"Fail safe control or symptom caused by error" for the item ""N"
blinks at range shift display (2)" was corrected
8-S17
• Wrong Correction
Item no. 64 is "Suspension pressure sensor".
Item no. 65 is "Suspension stroke sensor". 8-S69
• Topic "Sensor Resistance" was added. 8-S108
• Wrong Correction
Correct:
Voltage across the terminal 1 - chassis is approx. battery voltage. 8-S112
• Topic "Temperature Sensor (Build in Air Flow Sensor) Resistance"
was added. 8-S115
• Wrong Correction
Correct:
Wiring color for terminal 1 is Blue/Yellow 8-S122
• Wrong Correction
Correct:
Terminals to measure the hand throttle lever sensor resistance are
terminal 2-3 and terminal 2-4 8-S122
Last digit
of the
Code No.
Issue
month
Main Revised Point and Corrective Measures {Search word}
Reference
Page
KiSC issued 03, 2016 A
