Kubota MX4800 - OPERATING THE TRACTOR; New Tractor Break-in Procedures; Boarding and Leaving the Tractor; Operating Foldable ROPS

7IMPLEMENT LIMITATIONS
A Implement size may vary depending on soil operating conditions.
No. Implement Remarks MX4800 / MX5200 / MX5800
1Trailer
Max. load capacity kg (lbs.) 3500 (7700)
Max. drawbar load kg (lbs.) 750 (1650)
2 Mower
Rotary-Cutter
Max. cutting width mm (in.) 2130 (84)
Max. weight kg (lbs.) 450 (1000)
Flail Mower
Max. cutting width mm (in.) 1830 (72)
Max. weight kg (lbs.) 500 (1100)
Sickle Bar
Max. cutting width mm (in.) 2130 (84)
Max. weight kg (lbs.) 500 (1100)
3 Sprayer
Rear mounted Max. tank capacity L (gals.) 500 (130)
Pull type Max. tank capacity L (gals.) 2000 (529)
4 Rotary Tiller Max. tilling width mm (in.) 1830 (72)
5 Bottom Plow Max. size 16 in. x 2
6 Disk harrow : Pull type
Max. harrowing width mm (in.) 2130 (84)
Max. weight kg (lbs.) 400 (880)
7 Chisel Plow
Max. width mm (in.) 1830 (72)
Max. weight kg (lbs.) 350 (770)
8 Broad Caster
Max. tank capacity L (gals.) 300 (80)
Max. weight kg (lbs.) 100 (220)
9 Manure Spreader Max. capacity kg (lbs.) 2000 (4400)
10 Cultivator
Max. width mm (in.) 2450 (96)
Number of rows 4
Max. weight kg (lbs.) 400 (880)
11 Front Blade
Max. cutting width mm (in.) 1830 (72)
Max. oil pressure MPa (psi) 17.2 (2490)
Sub frame Necessary
12 Rear Blade
Max. cutting width mm (in.) 1830 (72)
Max. oil pressure MPa (psi) 17.2 (2490)
13 Front-end Loader
Max lifting capacity kg (lbs.) 850 (1870)
Max. oil pressure MPa (psi) 17.2 (2490)
Sub frame Necessary
14 Box Blade
Max. cutting width mm (in.) 1830 (72)
Max. weight kg (lbs.) 450 (1000)
15 Back Hoe
Max. digging depth mm (in.) 2288 (90)
Max. weight kg (lbs.) 450 (990)
Sub frame Necessary
16 Snow Blade
Max. width mm (in.) 1830 (72)
Max. weight kg (lbs.) 400 (880)
