Familiarising yourself with the machine
24
Weights
Tractor equipment
required
Total weight 570 kg
Load supported on parking stand 150 kg
Output / connections
Minimum output of the tractor 15 kW (20 hp)
Lighting equipment power supply 12 V, 7-pin plug socket ISO 1724
Hydraulic connections 1 x single-acting hydraulic control device
Hydraulic pressure 150 - 210 bar
Maximum PTO shaft speed 540 rpm
Pending attachment In accordance with ISO 6489-3
Alternatively: lower link and lift link drawbar Fixable in height and laterally
