S-28
SM-E3B SERIES WSM
DIESEL ENGINE
[2] DISASSEMBLING AND ASSEMBLING
(1) Draining Engine Oil and Coolant
Draining Engine Oil
1. Start and warm up the engine for approx. 5 minutes.
2. Place an oil pan underneath the engine.
3. Remove the drain plug (2) to drain oil.
4. After draining, screw in the drain plug.
(When refilling)
• Fill the engine oil up to the upper line on the dipstick (1).
• Never mix two different types of oil.
• Use the proper SAE Engine Oil according to ambient
temperature.
W1023464
Draining Coolant
• Never remove radiator cap while operating or immediately
after stopping. Otherwise, hot water will spout out from the
radiator. Wait for more than ten minutes to cool the radiator,
before opening the cap.
1. Prepare a bucket. Open the coolant drain cock.
W1023496
(1) Dipstick
(2) Drain Plug
(3) Oil Inlet Plug
(1) Coolant Drain Cock
To Next Page
