Kubota U17-3 Tier4 User Manual

44
3. For additional safety, use blocks or
supports under the ramps and the truck
bed.
4. Align the ramps and the tracks and
then drive the excavator slowly up the
ramps. After ensuring that the tracks are
completely on the truck bed, swivel the
upper body around to the back of the
truck.
5. Block the tracks and wire down the
excavator.
6. Before unloading, remove the swing lock
pin and then raise the dozer and bucket
from the truck bed.

Kubota U17-3 Tier4 Specifications

General

Engine Model	Kubota D902-E4
Engine Power	16.1 HP
Bucket Capacity	0.04 - 0.07 m³
Height	2, 490 mm
Bucket Breakout Force	3417 lbs
Travel Speed	2.5 mph
Max Digging Depth	7 ft 7 in
Width	980 mm
