Kubota V2403-M-DI-T User Manual

S-10
03-M-E3B, 03-M-DI-E3B, 03-M-E3BG WSM
DIESEL ENGINE
ENGINE BODY (Continued)
W1015276
Item Factory Specification Allowable Limit
Rocker Arm Shaft to Rocker Arm
Rocker Arm Shaft
Rocker Arm
Oil Clearance
O.D.
I.D.
0.016 to 0.045 mm
0.00063 to 0.0017 in.
13.973 to 13.984 mm
0.55012 to 0.55055 in.
14.000 to 14.018 mm
0.55119 to 0.55188 in.
0.10 mm
0.0039 in.
–
–
Push Rod Alignment – 0.25 mm
0.0098 in.
Tappet to Tappet Guide
Tappet
Tappet Guide
Oil Clearance
O.D.
I.D.
0.020 to 0.062 mm
0.00079 to 0.0024 in.
23.959 to 23.980 mm
0.94327 to 0.94409 in.
24.000 to 24.021 mm
0.94489 to 0.94570 in.
0.07 mm
0.003 in.
–
–
Timing Gear
Crank Gear to Idle Gear
Idle Gear to Cam Gear
Idle Gear to Injection Pump Gear
Crank Gear to Oil Pump Gear
Idle Gear to Balancer Gear
(Balancer Model Only)
Cam Gear to Balancer Gear
(Balancer Model Only)
Crank Gear to Idle Gear 2
(Side PTO Model Only)
Idle Gear 2 to Hydraulic Pump Drive Gear
(Side PTO Model Only)
Backlash
Backlash
Backlash
Backlash
Backlash
Backlash
Backlash
Backlash
0.04150 to 0.1122 mm
0.001634 to 0.004417 in.
0.04150 to 0.1154 mm
0.001634 to 0.004543 in.
0.04150 to 0.1154 mm
0.001634 to 0.004543 in.
0.04150 to 0.1090 mm
0.001634 to 0.004291 in.
0.03500 to 0.1160 mm
0.001378 to 0.004566 in.
0.03500 to 0.1160 mm
0.001378 to 0.004566 in.
0.04150 to 0.1154 mm
0.001634 to 0.004543 in.
0.03080 to 0.1062 mm
0.001213 to 0.004181 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
Idle Gear Side Clearance 0.12 to 0.48 mm
0.0048 to 0.018 in.
0.9 mm
0.04 in.
Idle Gear Shaft to Idle Gear Bushing
Idle Gear Shaft
Idle Gear Bushing
Oil Clearance
O.D.
I.D.
0.025 to 0.066 mm
0.00099 to 0.0025 in.
37.959 to 37.975 mm
1.4945 to 1.4950 in.
38.000 to 38.025 mm
1.4961 to 1.4970 in.
0.10 mm
0.0039 in.
–
–
