CLUTCH
L3560, L4060, L4760, L5060, L5460, L6060, WSM
2-S2
2. SERVICING SPECIFICATIONS
9Y1210824CLS0002US0
Item Factory Specification Allowable Limit
Clutch Pedal Free travel 20 to 30 mm
0.78 to 1.18 in.
–
Clutch Disc Boss and Gear Shaft
(Manual Transmission and GST)
Backlash
(Displacement
Around Disc Edge)
– 2.0 mm
0.079 in.
Clutch Coupling Boss and Input Shaft
(HST)
Backlash
(Displacement
Around Clutch
Coupling)
– 1.5 to 2.0 mm
0.059 to 0.078 in.
Clutch Disc Disc Surface to
Rivet Top (Depth)
– 0.3 mm
0.01 in.
Diaphragm Spring Mutual Difference – 0.5 mm
0.02 in.
Pressure Plate Flatness – 0.2 mm
0.008 in.
To Next Page
