Putting into service
Rotary cultivators
EL32
21

Preparing the machine
Axial or offset working position
Axial working position:
Offset working position:
Offset width depending on model:
EL 32 - 105 = 215 mm (8.6’’).
EL 32 - 130 = 315 mm (1’.4’’).
EL 32 - 150 = 420 mm (1’.4.6’’).
EL 32 - 190 = 0 mm (0’’).
