1
INSTRUCTION MANUAL
PRIMOR STRAW BLOWER
A7310104 3 09-00
PLEASE READ CAREFULLY BEFORE USING THE MACHINE

Table of Contents

Questions and Answers

  • E
    Erika HahnJul 27, 2025
    What to do if KUHN Farm Equipment turbine fails to rotate?
    • T
      Timothy RiceJul 27, 2025
      If the turbine fails to rotate, and the overload clutch is slipping, it might be jammed. First, switch off the tractor engine and disengage the tractor PTO. Then, check for any product buildup in the turbine. If there is buildup, use the hook on the right-hand side of the machine to pull out the jammed product at the distribution chute or beater bar. Use a lever to ensure the turbine can rotate freely. Once released, run the turbine empty for a few seconds until it reaches its normal working speed.
  • E
    Erin SnyderAug 3, 2025
    Why is my KUHN Farm Equipment turbine rattling when PTO is engaged?
    • A
      Amy CarrollAug 3, 2025
      If the turbine rattles when the PTO is engaged, the clutch may be slipping intermittently. To resolve this, gradually engage the PTO to a suitable speed. If your machine has a free-wheel drive shaft and your tractor has a hydraulic PTO clutch, consult your dealer, as there may be a problem with the progressive clutch rate, irrespective of tractor engine speed.
  • J
    Joshua BurnsAug 9, 2025
    What to do if KUHN Farm Equipment chute movement is too quick?
    • K
      Kelly SkinnerAug 9, 2025
      If the chute movement is too quick, it's likely that the flow limiters are open too far. Adjust the flow limiters to correct this.
  • S
    samantha31Aug 14, 2025
    How to resolve loading difficulties in KUHN Farm Equipment?
    • C
      Christine ShermanAug 14, 2025
      If you're experiencing loading difficulties due to insufficient gate power, it could be a hydraulic problem. Check that the hydraulic connection between the tractor and the machine is correct, ensuring proper pressure and return. Have your dealer check the hydraulic pressure (180 bar) and the pump flow (30 l/min). The return pressure must be 8 bar maximum at nominal tractor engine speed.
  • C
    Carmen WhiteAug 21, 2025
    What to do if the turbine is rotating and the beater bar is moving forwards in KUHN Farm Equipment?
    • D
      David BrownAug 21, 2025
      If the turbine is rotating and the beater bar is moving forwards, there might be a few reasons: the conveyor is set to 0, the beater bar is jammed, or there's insufficient beater bar and conveyor power. Set the conveyor speed to the appropriate mark. Decompress the product inside the body with the gate. Briefly switch the conveyor to reverse and then back to forward motion. Refer to the section on loading difficulties for hydraulic problem solutions.

Summary

Important Information

General Data

Essential machine references and commissioning date for user requirements.

Optional Equipment

Checkboxes to indicate optional equipment fitted to the machine.

About Improvements

Safety

Designated Use of the Machine

Specifies intended uses and liabilities for misuse of the straw blower.

General Safety Recommendations

General safety advice for machine operation, maintenance, and traffic.

General Points

Numbered safety and operational points for safe use and transport.

Hitching

Trailed PRIMOR

Procedures for hitching the trailed version to a tractor securely.

Mounted PRIMOR

Procedures for hitching the mounted version to a tractor securely.

Driving Components (PTO and Universal Drive Shafts)

Hydraulic Circuit

Electrical Circuit

Tyres

Servicing

Labels Relating to Safety

Lighting Equipment

Trailed PRIMOR

Specific lighting equipment components for the trailed version.

Description Straw Blower PRIMOR

Technical Specifications

Mounted PRIMOR

Technical specifications for the mounted version of the Primor straw blower.

Semi-Mounted PRIMOR

Technical specifications for the semi-mounted version of the Primor straw blower.

Description of the Controls

Teleflex Cables Remote Controls

Explanation of how to operate teleflex cable remote controls for machine functions.

Electrical Control

Starting Up

Adjusting the Position of the Controls

Remote Control Cables

Mounting options for remote control units on the machine or tractor.

Electric Control Unit

User choices for locating the electric control unit.

Transmission

Working Parts (PTO and Universal Drive Shafts)

Instructions for safe connection, use, and maintenance of PTO and drive shafts.

Connections

Hydraulic

Connecting the machine's hydraulic system to the tractor's hydraulics.

Electrical

Connecting the machine's electrical system and lighting to the tractor.

Preliminary Checks

No-Load Tests

Unhitching

Machine Operation

Loading Bales

Step-by-step guide for loading bales onto the machine.

Spreading

Procedures for operating the machine to spread material.

Transportation

Guidelines for safely transporting the machine on public roads and land.

Safety

Wide Angle PTO Shaft

Cat. 2;3 Linkage Bar

Straw Blowing Chute on Primor Straw Blower; Chopper

Regulating Combs for Rectangular Bales

Maintenance

Conveyor Chain Tension

Procedure for checking and adjusting conveyor chain tension.

Tyres

Checks and specifications for tyre pressure and wheel nut tightness.

Oil Change and Level Check

Procedures for changing and checking oil in the gearbox and conveyor unit.

Maintenance Schedule

Schedule of recommended maintenance tasks and intervals for the machine.

Storage

Instructions for preparing the machine for long-term storage.

Troubleshooting

General Conditions of Warranty
