OPERATOR'S MANUAL
Mower conditioner
FC243
KN123BGB C
- English - 02-2006

Table of Contents

Questions and Answers

  • M
    Mrs. Debbie MartinAug 2, 2025
    How to fix uneven stubble with KUHN Farm Equipment?
    • R
      Robin FuentesAug 2, 2025
      If you notice uneven stubble when using your KUHN Farm Equipment, it might be due to several reasons. First, check if the knives are dull or broken and replace them if necessary. Also, ensure that the knives are installed correctly, with the arrow on the knife's upper face pointing in the disc's direction of rotation. Finally, verify that the PTO speed is at the correct level; increase it to 540 min-1 if it's too low.
  • A
    Alexandra JohnsonAug 6, 2025
    What to do if soil builds up in front of the cutterbar on KUHN FC243 Farm Equipment?
    • K
      kayleewilsonAug 6, 2025
      If you find soil building up in front of the cutterbar of your KUHN Farm Equipment, it could be due to too much cutterbar down pressure. Try increasing the accumulator pressure to resolve this. Very wet working conditions can also cause this issue, so increasing the accumulator pressure might help in those situations as well.
  • C
    Cynthia AllenAug 12, 2025
    What to do if the conditioning rotor is obstructed in KUHN FC243 Farm Equipment?
    • L
      Lori WrightAug 12, 2025
      If the conditioning rotor in your KUHN Farm Equipment is obstructed, it could be due to a few reasons. Make sure the rotor drive belts are correctly tensioned to ensure sufficient rotor speed. Also, check that the PTO speed is at the correct level and increase it to 540 min-1 if it's too low. Lastly, ensure that the swath shields are not too closed; open them up to allow for better flow.
  • R
    Renee BoyerAug 17, 2025
    Why are windrows badly shaped with KUHN FC243 Farm Equipment?
    • J
      jjohnsonAug 17, 2025
      If your KUHN Farm Equipment is producing badly shaped windrows, it could be caused by a PTO speed that is too low; increase the speed to 540 min-1. Another potential cause is incorrectly adjusted swath shields, so make sure to adjust both of them.
  • L
    larsennancyAug 22, 2025
    Why is ground contour adaptation bad with KUHN FC243?
    • T
      timothy00Aug 22, 2025
      If your KUHN Farm Equipment isn't adapting well to the ground contour, start by adjusting the main frame height with regards to the ground. Excessive ground speed can also cause this, so reduce your speed. Additionally, insufficient ground pressure might be the issue; in this case, reduce the accumulator pressure.
  • D
    desiree91Aug 27, 2025
    What causes excessive lateral oscillation in transport position for KUHN Farm Equipment?
    • D
      danakennedyAug 27, 2025
      If the mowing-conditioning unit on your KUHN Farm Equipment is oscillating excessively in the transport position, the transport stop adjustment may be incorrect. Readjust the transport stop to resolve this issue.

Summary

Identification of the Machine

Rear View

Diagram illustrating the rear view of the mower conditioner.

Model Identification Plate

Details the machine's identification plate for spare parts and serial numbers.

Optional Equipments

Lists optional equipment available for the machine.

Safety

Symbol Descriptions

Explains the meaning of symbols used in the manual and on the machine for safety.

Safety Instructions

Provides essential safety guidelines and precautions for operating the machine.

Safety Decals

Shows the location and meaning of safety decals placed on the machine.

Road Safety

Outlines necessary safety equipment and recommendations for road use.

Machine Specifications

Description and Glossary

Defines key terms and components related to the machine's specifications.

Technical and Sound Specifications

Lists detailed technical data, including dimensions, speeds, and noise levels.

Putting into Service

Control Elements and Coupling

Describes control elements and procedures for coupling/uncoupling the machine.

Tractor and Machine Preparation

Steps for preparing the tractor and the machine prior to coupling.

Connections (Hydraulic, Electrical, PTO)

Details on connecting hydraulic, electrical systems, and PTO shafts.

Machine Adjustment and Uncoupling

Procedures for adjusting the machine and safely uncoupling it.

Instructions for Transport

Transport Position

Steps to safely move the machine into its transport position.

Road Regulations Compliance

Ensures adherence to highway code and regulations during transport.

Instructions for Work

Deploying to Work Position

Steps to safely move the machine from transport to working configuration.

Cutting Height Adjustment

How to adjust the cutting height for optimal crop management.

Ground Pressure Settings

Procedures for setting and checking ground pressure for safety and performance.

Conditioning Intensity and Rotor Speed

Adjusting conditioning intensity, rotor speed, and comb position.

Swathing System Adjustment

How to adjust the swath shields for desired swath width.

Optional Equipments

Swath Shield Extensions

Details on using swath shield extensions to reduce swath width.

Wide Spreading System

Information on the wide spreading kit for even crop distribution.

Maintenance and Storage

Maintenance Schedule

A frequency chart for routine maintenance tasks based on usage.

Cleaning and Lubrication

Procedures for cleaning the machine and lubricating its components.

PTO Shaft Maintenance

Maintenance procedures for primary and secondary PTO shafts.

Gearbox and Cutterbar Oil

Instructions for draining and refilling cutterbar and gearbox oil levels.

Accumulator and Drive System Maintenance

Maintenance for hydro-pneumatic accumulators, drive systems, and transport stops.

Belt Maintenance and Replacement

Checking belt tension and procedures for replacing belts.

Knife, Disc, and Cone Inspection

Inspecting and replacing knives, discs, and cone components.

Storage Procedures

Guidelines for storing the machine at the end of the season and preparing it.

Trouble Shooting Guide

Stubble and Soil Buildup Issues

Solutions for uneven stubble and soil buildup problems.

Ground Adaptation and Clearance Problems

Addressing issues with ground contour adaptation and cutterbar clearance.

Rotor Obstruction and Windrow Shape

Troubleshooting rotor obstructions and correcting badly shaped windrows.

Limited Warranty

Warranty Conditions and Exceptions

Details warranty coverage, exclusions, and customer responsibilities.

Warranty Claim Procedure

Explains the process for submitting a warranty claim and required information.

KUHN FC243 Specifications
