Instructions for work
Mower conditioner
FC243
43
Conditioning intensity
Several factors govern the conditioning intensity
adjustment:
Conditioning rotor speed
See section "Finger conditioning rotor speed".
Control lever (1)
The lever sets the conditioning hood in relation to the
rotor in 6 positions.
To increase the conditioning intensity, reduce the
distance between the conditioning hood and the
conditioning rotor.
To reduce the conditioning intensity (for mowing
leguminous for example), increase the distance between
the conditioning hood and the conditioning rotor.
Before adjusting, maintaining or repairing
the machine, turn off ignition key and wait
until all moving parts have come to a
complete stop.
Refer to the pictorial applied on the machine to
check the lever direction of operation with
regards to the required conditioning intensity.
